Plain Channel Steel (Structural U-Channel)

Plain Channel Steel (Structural U-Channel)

Structural steel Plain Channels (U-Shape) available in Hot Rolled and Galvanized finishes. Manufactured to JIS G 3350 SSC 400 and SS 104 standards.

  • Profile: U-Channel (Unlipped)

  • Standard: JIS G 3350 SSC 400 / SS 104

  • Finish: Hot Rolled / Galvanized

Order via WhatsApp
Categories: , , Tags: , , , , , ,

Description

Overview Allied Plain Channels are versatile structural steel sections used for general framing, bracing, and support structures. Available in a wide range of sizes from 100mm up to 250mm web height.

Technical Specifications

  • Standard Compliance: JIS G 3350 SSC 400 / SS 104.

  • Tolerances (JIS G 3350):

    • Height < 150mm: ± 1.5mm

    • Height > 150mm: ± 2.0mm

    • Thickness: ± 0.22mm to ± 0.60mm (depending on gauge).

Dimensions & Specifications

Dimension HxAxC (mm) Thickness (mm) Calculated Weight (kg/m)
100 x 50 x 50 1.6 – 2.3 2.65 – 3.73
125 x 50 x 50 1.6 – 2.3 2.97 – 4.18
150 x 65 x 65 2.0 – 2.3 4.54 – 5.20
175 x 75 x 75 2.0 – 2.3 5.25 – 6.02
200 x 75 x 75 2.3 – 3.2 6.47 – 8.93
250 x 75 x 75 2.3 – 4.5 7.37 – 14.22
