Description

The XGQT2 FLEXIBLE COUPLING is a standard flexible coupling designed for a wide range of general piping applications under moderate pressure services. The coupling provides excellent flexibility to accommodate misalignment, distortion, thermal expansion, vibration, noise, and seismic movement. It also allows for curved piping layouts, making installation more adaptable and efficient.

Sizes Available: 50 mm – 300 mm

Working Pressure: Up to 20 Bar / 300 PSI

Maximum working pressures are based on CWP (Cold Water Pressure) or the maximum allowable working pressure within the service temperature range of the gasket used in the coupling. Ratings are based on standard wall or Schedule 7/10/40 steel pipe, cut or roll-grooved to ANSI/AWWA C606-04 specifications. Actual ratings may differ from UL, ULC, or FM approved ratings due to varying testing conditions and pipe specifications.

Housing Coating: Red Enamel

Housing Material: Ductile Iron conforming to ASTM A536 Grade 65-45-12

Gasket Material: EPDM (Silicon Free)

The EPDM gasket provides excellent self-sealing capability and is designed to ensure a reliable leak-tight seal with long-lasting sealing performance.
